RCA Receiving Tube Manual (1975) -- Article Index and Intro

Home | Audio Magazine | Stereo Review magazine | Good Sound | Troubleshooting



Contents

  1. ELECTRONS, ELECTRODES, AND ELECTRON TUBES
  2. ELECTRON TUBE CHARACTERISTICS
  3. ELECTRON TUBE APPLICATIONS
  4. ELECTRON TUBE INSTALLATION
  5. SAFETY PRECAUTIONS--RECEIVING TUBES, PICTURE TUBES
  6. INTERPRETATION OF TUBE DATA
  7. ELECTRON TUBE TESTING
  8. APPLICATION GUIDE FOR RECEIVING TUBES
  9. TECHNICAL DATA FOR RECEIVING TUBES ENTERTAINMENT AND INDUSTRIAL TYPES
  10. CHARACTERISTICS CHART FOR ENTERTAINMENT AND INDUSTRIAL RECEIVING TUBES (includes discontinued types)
  11. TERMINAL DIAGRAMS FOR RECEIVING TUBES
  12. OUTLINES
  13. STRUCTURE OF A MINIATURE TUBE
  14. RESISTANCE-COUPLED AMPLIFIERS
  15. REPLACEMENT GUIDE--ENTERTAINMENT RECEIVING TYPES
  16. REPLACEMENT GUIDE--INDUSTRIAL RECEIVING TYPES
  17. PICTURE TUBE CHARACTERISTICS CHART
  18. TERMINAL DIAGRAMS FOR PICTURE TUBES
  19. CIRCUITS
  20. INDEX



RCA Receiving Tube Manual (1975) -- Including Picture Tubes and Industrial Receiving Tubes

THIS MANUAL, like its many predecessors, has been prepared to assist those who work or experiment with home-entertainment or industrial receiving types of electron tubes and circuits or with tele vision picture tubes. It will be found valuable by engineers, service technicians, educators, experimenters, electricians, radio amateurs, hobbyists, students, and others interested in electron tubes and their applications.

Easy-to-read chapters explain the basic principles of operation, significant electrical characteristics, circuit applications, and testing of various types of electron tubes. Technical data are given on current RCA home-entertainment and industrial receiving-type tubes and on picture tubes. Circuit diagrams are given illustrating the use of RCA tubes in many practical applications. Also included are expanded and updated replacement guides for obsolete or hard-to-find industrial and home-entertainment receiving tubes.

RCA, Distributor and Special Products Division Cherry Hill Offices, Camden, N.J. 08101 USA. Copyright 1975 by RCA Corporation (All rights reserved under Pan-American Copyright Convention)
